Deskripsi Produk DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 —
DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 —
DIAL INDICATOR 2/0.001MM 2113S-10 adalah satu alat ukur yang dapat mengukur kerataan benda kerja. Dial indicator Mitutoyo memungkinkan kita untuk memeriksa kerataan dari permukaan benda, memeriksa penyimpangan yang kecil pada bidang , memeriksa penyimpanga n eksentris, memeriksa kesejajaran permukaan benda, menyetel kesentrisan benda pada pencekam mesin bubut, dan memeriksa penyimpangan bantalan pada poros engkol . Dial indicator Mitutoyo standard mempunyai range pengukuran 0-2 MM dan pembacaan 0-100-0 sering digunakan di industri , bengkel, laboratorium, atau konstruksi.
Benefit :
- Standard 0.001MM and 0.005MM graduation dial indicators having a bezel with an outside diameter of Dia.57MM. All types come with limit markers and a bezel clamp.
- The outer clamp and lifting lever (optional) can be attached to either the right or left side. These part s can be easily installed and removed without tools.
- Secure adhesi on between the bezel and crystal as well as the use of an O-ring prevent s water or oil penetration.
- The spindle is made of high-strength quenchhardened stainless steel which resists arduous use.
- A car bide contact point is used.
- A special alloy is used for the sector gears to provide improved wear resistance.
- The indicator uses jeweled bearings, providing excellent indication sensitivity and durability.
- Application of a hard coating on the surfac e of the crystal makes the gauge highly scratch- and chemical-resistant.
|
Fitur :
- The stem spindle is made of high strength quench hardened stainless steel which resists strenuous use also carbide contact point is used
- The grand gear uses stainless steel that is resistant to wear and deformation, application of a hard coating on the surface of the crystal makes the gauge highly scratch and chemical resistant
- Ste m diameter 8MM, M2.5-0.45 thread size and Measuring force is 1.5N or less
- Shockproof, jeweled bearing
- Provided with inspection certificate
|
Spesifikasi :
- Part Number : 2113S-10
- Style Name : 0-100
- Maximum Measurement : 0-2MM
- Additional Features : Shockproof, Jeweled Bearing
- Color : White
- Display : 0-100-0
- EAN : 4946368423470
- Measurement Accuracy : +/-0.007MM
- Numb er of Items : 1
- Outside Diameter : 57 MM
- Range : 0-2MM
- Resolution : 0.001MM
- Shape : Lug Back
- Size : 0- 2MM Range
|
