AC Clamp Meter HIOKI 3280-70F

Rp2.860.000

Spesifikasi DetailĀ AC Clamp Meter HIOKI 3280-70F:

  • Ac Clamp Meter HIOKI 3280-70F
  • AC Current 41.99 to 1000 A, 3 ranges (50 to 60 Hz, Average rectified),
  • Basic accuracy: 1.5 % rdg. 5 dgt.
  • DC Voltage 419.9 mV to 600 V, 5 ranges, Basic accuracy: 1.0 % rdg. 3 dgt.
  • AC Voltage 4.199 V to 600 V, 4 ranges
  • (45 to 500 Hz, Average rectified),
  • Basic accuracy: 1.8 % rdg. 7 dgt.
  • Crest factor N/A
  • Resistance 419.9 to 41.99 M, 6 ranges, Basic accuracy: 2 % rdg. 4 dgt.
SKU: AC Clamp Meter HIOKI 3280-70F Category: Tag:

Description

Jual AC Clamp Meter HIOKI 3280-70F, barang dijamin asli dan bergaransi resmi Hioki Indonesia hanya di alatproyek

Spesifikasi DetailĀ AC Clamp Meter HIOKI 3280-70F:

  • Ac Clamp Meter HIOKI 3280-70F
  • AC Current 41.99 to 1000 A, 3 ranges (50 to 60 Hz, Average rectified),
  • Basic accuracy: 1.5 % rdg. 5 dgt.
  • DC Voltage 419.9 mV to 600 V, 5 ranges, Basic accuracy: 1.0 % rdg. 3 dgt.
  • AC Voltage 4.199 V to 600 V, 4 ranges
  • (45 to 500 Hz, Average rectified),
  • Basic accuracy: 1.8 % rdg. 7 dgt.
  • Crest factor N/A
  • Resistance 419.9 to 41.99 M, 6 ranges, Basic accuracy: 2 % rdg. 4 dgt.
  • Other functions Continuity: Buzzer sounds at 50 40 or less, Data hold, Auto power save, Drop-proof from height of 1 meter
  • Display LCD, max. 4199 dgt., Display refresh rate: 400 ms
  • Environmental protection IP40 dustproof and waterproof
  • Power supply Coin type lithium battery (CR2032) 1, Continuous use 120 hours
  • Core jaw dia. 33 mm (1.30 in)
  • Dimensions and mass 57 mm (2.24 in) W 175 mm (6.89 in) H 16 mm (0.63 in) D, 100 g (3.5 oz)
  • Accessories CARRYING CASE 9398 1, TEST LEAD L9208 1, Coin type lithium battery (CR2032) 1, Instruction manual 1
  • Core jaw dia. 130 mm (5.12 in) (Cable cross-section diameter: 5 mm (0.20 in); tip cap diameter: 7 mm (0.28 in))
  • AC Current 419.9 A/ 4199 A, 2 ranges (3.0 % rdg. 5 dgt.)
  • Cable length 800 mm (31.5 in)

Additional information

Weight 2 kg
Brand

Hioki
